*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Radiation Hardening | No |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| Operating Supply Voltage | 5V |
| Number of Channels | 4 |
| Packaging | Tube |
| Number of Pins | 16 |
| Max Operating Temperature | 85°C |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| Min Operating Temperature | 0°C |
| Published | 2000 |
| Max Supply Voltage | 5.25V |
| Nominal Supply Current | 40mA |
| Min Supply Voltage | 4.75V |
| Voltage – Supply | 4.75V~5.25V |
| Output Type | TTL |
| Output | TTL |
| Package / Case | 16-SOIC (0.295, 7.50mm Width) |
| Differential – Input:Output | Yes/Yes |
| Low Level Output Current | 24mA |
| Frequency (Max) | 160MHz |
| Supplier Device Package | 16-SOIC |
| Operating Temperature | 0°C~85°C |
| Type | Fanout Buffer (Distribution) |
| Logic Function | Translator |
| Ratio – Input:Output | 1:4 |
| Input | PECL |
| Propagation Delay | 3.7 ns |
| Turn On Delay Time | 3.7 ns |
| Series | Precision Edge? |
| High Level Output Current | -15mA |
| Base Part Number | SY10H841 |
