*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Part Status | Active |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Number of Ports | 2 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Surface Mount | YES |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Terminal Position | DUAL |
| Operating Temperature | -40°C~85°C |
| Interrupt Output | Yes |
| Qualification Status | Not Qualified |
| Number of Bits | 16 |
| Number of I/O | 16 |
| Terminal Form | GULL WING |
| Technology | CMOS |
| Factory Lead Time | 7 Weeks |
| Published | 2010 |
| Supply Voltage | 1.8V |
| Number of Terminations | 24 |
| Pin Count | 24 |
| HTS Code | 8542.39.00.01 |
| Terminal Pitch | 0.65mm |
| Width | 4.4mm |
| Height Seated (Max) | 1.1mm |
| Clock Frequency | 400kHz |
| Length | 7.8mm |
| Voltage – Supply | 1.65V~5.5V |
| JESD-30 Code | R-PDSO-G24 |
| Package / Case | 24-TSSOP (0.173, 4.40mm Width) |
| Output Type | Open Drain, Push-Pull |
| Interface | I2C, SMBus |
| Power Supplies | 1.8/5V |
| Feature | POR |
| Current – Output Source/Sink | 10mA 25mA |
| Series | Agile |
| Base Part Number | PCAL9555A |
