*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Number of Functions | 1 |
| Number of Circuits | 1 |
| RoHS Status | RoHS Compliant |
| Pbfree Code | yes |
| Radiation Hardening | No |
| JESD-609 Code | e3 |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| Operating Temperature | -40°C~85°C |
| Supply Voltage | 2.5V |
| Factory Lead Time | 4 Weeks |
| Published | 2010 |
| Terminal Finish | Tin (Sn) |
| Number of Pins | 32 |
| Number of Terminations | 32 |
| Pin Count | 32 |
| Length | 5mm |
| Width | 5mm |
| Terminal Pitch | 0.5mm |
| Terminal Position | QUAD |
| Output | LVPECL |
| Nominal Supply Current | 100mA |
| Halogen Free | Halogen Free |
| Supply Voltage-Min (Vsup) | 2.375V |
| Supply Voltage-Max (Vsup) | 2.625V |
| Differential – Input:Output | Yes/Yes |
| Power Supplies | 2.5/3.3V |
| Quiescent Current | 125mA |
| Package / Case | 32-VFQFN Exposed Pad |
| Subcategory | Clock Drivers |
| Prop. Delay@Nom-Sup | 0.25 ns |
| fmax-Min | 6 MHz |
| Frequency (Max) | 7GHz |
| Input | CML, LVDS, LVPECL |
| Family | 7L |
| Ratio – Input:Output | 4:2 |
| Propagation Delay | 160 ps |
| Voltage – Supply | 2.37V~3.6V |
| Type | Fanout Buffer (Distribution), Multiplexer, Translator, Data |
| Additional Feature | CAH ALSO USE 3.6 V SUPPLY |
| Base Part Number | NB7LQ572 |
