*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Part Status | Active |
| RoHS Status | ROHS3 Compliant |
| Number of Functions | 2 |
| Number of Circuits | 2 |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Packaging | Tape & Reel (TR) |
| ECCN Code | EAR99 |
| Pbfree Code | yes |
| Radiation Hardening | No |
| JESD-609 Code | e3 |
| Lead Free | Lead Free |
| Operating Temperature | -40°C~85°C |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Number of Outputs | 20 |
| Supply Voltage | 2.5V |
| Operating Supply Voltage | 2.5V |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Height Seated (Max) | 1.6mm |
| Terminal Finish | Tin (Sn) |
| Published | 2005 |
| Number of Pins | 32 |
| Number of Terminations | 32 |
| Pin Count | 32 |
| Terminal Position | QUAD |
| Output | LVDS |
| Length | 7mm |
| Width | 7mm |
| Terminal Pitch | 0.8mm |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| Factory Lead Time | 21 Weeks |
| Nominal Supply Current | 150mA |
| Halogen Free | Halogen Free |
| Lifecycle Status | ACTIVE (Last Updated: 1 day ago) |
| Voltage – Supply | 2.375V~2.625V |
| Differential – Input:Output | Yes/Yes |
| Technology | ECL |
| Subcategory | Clock Drivers |
| Frequency | 1GHz |
| Package / Case | 32-LQFP |
| Type | Fanout Buffer (Distribution) |
| Ratio – Input:Output | 1:5 |
| Series | 100EP |
| Input | LVDS, LVPECL |
| Propagation Delay | 650 ps |
| Turn On Delay Time | 675 ps |
| Prop. Delay@Nom-Sup | 0.675 ns |
| Base Part Number | MC100EP210 |
