*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Number of Functions | 1 |
| Number of Circuits | 1 |
| RoHS Status | Non-RoHS Compliant |
| Part Status | Obsolete |
| Supply Voltage | 5V |
| Packaging | Tube |
| Operating Temperature | -40°C~85°C |
| Lead Free | Contains Lead |
| Qualification Status | Not Qualified |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Reach Compliance Code | not_compliant |
| Published | 2006 |
| Number of Terminations | 28 |
| Number of Pins | 28 |
| Pin Count | 28 |
| Terminal Position | QUAD |
| Terminal Form | J BEND |
| Peak Reflow Temperature (Cel) | 240 |
| Height Seated (Max) | 4.57mm |
| Differential – Input:Output | Yes/Yes |
| Supply Voltage-Min (Vsup) | 4.2V |
| Technology | ECL |
| Subcategory | Clock Drivers |
| Package / Case | 28-LCC (J-Lead) |
| Frequency (Max) | 900MHz |
| Terminal Finish | Tin/Lead (Sn80Pb20) |
| Supply Voltage-Max (Vsup) | 5.7V |
| Power Supplies | -4.5V |
| Type | Fanout Buffer (Distribution), Multiplexer |
| Voltage – Supply | 4.2V~5.7V |
| Output | ECL, PECL |
| Input | ECL, PECL |
| Same Edge Skew-Max (tskwd) | 0.05 ns |
| Series | 100E |
| Propagation Delay (tpd) | 0.8 ns |
| Ratio – Input:Output | 2:8 |
| fmax-Min | 700 MHz |
| Prop. Delay@Nom-Sup | 0.85 ns |
| Additional Feature | NECL MODE: 0V VCC WITH VEE = -4.2V TO -5.7V |
| Base Part Number | MC100E310 |
