*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Adjustable Threshold | NO |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Cells | 1 |
| ECCN Code | EAR99 |
| Pbfree Code | yes |
| Radiation Hardening | No |
| JESD-609 Code | e3 |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| Terminal Position | DUAL |
| Packaging | Tube |
| Number of Pins | 16 |
| Number of Terminations | 16 |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Min Supply Voltage | 2.5V |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Max Supply Voltage | 5.5V |
| Operating Supply Voltage | 5.5V |
| Published | 2006 |
| Length | 5mm |
| Terminal Pitch | 0.65mm |
| Terminal Finish | MATTE TIN |
| Width | 4.4mm |
| Height | 1.1mm |
| Analog IC – Other Type | POWER SUPPLY SUPPORT CIRCUIT |
| Interface | I2C |
| Package / Case | 16-TSSOP (0.173, 4.40mm Width) |
| Nominal Supply Current | 60μA |
| Operating Supply Current | 60μA |
| Function | Battery Monitor |
| Battery Chemistry | Lithium-Ion |
| Operating Temperature | -20°C~70°C TA |
| Fault Protection | Over Current, Over/Under Voltage, Short Circuit |
| Output Voltage | 4.275V |
| Base Part Number | DS2764 |
