Product Details

*After successful submission, we will reply to you within 24 hours. Please check your email

Product Details

*The following are the basic parameters of the product, involving the characteristics of the product and its category

TYPEDESCRIPTION
Mounting TypeSurface Mount
MountSurface Mount
Number of Functions1
RoHS StatusRoHS Compliant
ECCN CodeEAR99
Pbfree Codeyes
JESD-609 Codee3
Lead FreeLead Free
Part StatusObsolete
Terminal PositionDUAL
Supply Voltage5V
PackagingTube
Qualification StatusNot Qualified
Operating Temperature (Min)-40°C
Terminal FormGULL WING
Peak Reflow Temperature (Cel)260
Moisture Sensitivity Level (MSL)3 (168 Hours)
Operating Supply Voltage12V
Time@Peak Reflow Temperature-Max (s)40
Supply Voltage-Max (Vsup)5.5V
Number of Terminations24
Number of Pins24
Pin Count24
Terminal Pitch1.27mm
Operating Temperature (Max)105°C
Terminal FinishTin (Sn)
Published2005
HTS Code8542.39.00.01
Temperature GradeINDUSTRIAL
Width7.5mm
Supply Voltage1-Min7.5V
Height Seated (Max)2.65mm
Supply Voltage1-Max14V
Package / Case24-SOIC (0.295, 7.50mm Width)
Nominal Supply Current340mA
SubcategoryPeripheral Drivers
Output Current Flow DirectionSOURCE SINK
Output Peak Current Limit-Nom0.07A
Lifecycle StatusOBSOLETE (Last Updated: 1 day ago)
Built-in ProtectionsOVER CURRENT; THERMAL
Length15.395mm
TypeAir Core Gauge Driver
Base Part NumberCS4122
