*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Number of Functions | 1 |
| Memory Width | 1 |
| RoHS Status | RoHS Compliant |
| Pbfree Code | yes |
| Radiation Hardening | No |
| Contact Plating | Gold |
| Lead Free | Lead Free |
| Part Status | Obsolete |
| JESD-609 Code | e4 |
| Number of Pins | 8 |
| Number of Terminations | 8 |
| Pin Count | 8 |
| Terminal Position | DUAL |
| Operating Supply Voltage | 5V |
| Supply Voltage | 3.3V |
| Technology | CMOS |
| Peak Reflow Temperature (Cel) | 260 |
| Published | 2011 |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Width | 2mm |
| Operating Temperature | -40°C~85°C TA |
| Terminal Pitch | 0.5mm |
| Data Retention Time-Min | 100 |
| Length | 3mm |
| Memory Type | Non-Volatile |
| Halogen Free | Halogen Free |
| Memory Interface | I2C |
| Serial Bus Type | I2C |
| Nominal Supply Current | 2mA |
| Supply Voltage-Min (Vsup) | 1.7V |
| Memory Format | EEPROM |
| Write Cycle Time – Word, Page | 5ms |
| Write Cycle Time-Max (tWC) | 5ms |
| Clock Frequency | 400kHz |
| Endurance | 1000000 Write/Erase Cycles |
| Package / Case | 8-WFDFN Exposed Pad |
| Interface | 2-Wire, I2C, Serial |
| Standby Current-Max | 0.000001A |
| Voltage – Supply | 1.7V~5.5V |
| Access Time | 900ns |
| Write Protection | HARDWARE |
| Memory Size | 16Kb 2K x 8 |
| Density | 16 kb |
| I2C Control Byte | 1010MMMR |
| Organization | 16KX1 |
| Base Part Number | CAT24C16 |
