*The following are the basic parameters of the product, involving the characteristics of the product and its category
| TYPE | DESCRIPTION |
|---|---|
| Part Status | Active |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Surface Mount |
| Mount | Surface Mount |
| Number of Channels | 1 |
| ECCN Code | EAR99 |
| Pbfree Code | yes |
| Adjustable Threshold | YES |
| Contact Plating | Gold |
| Lead Free | Lead Free |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| JESD-609 Code | e4 |
| Terminal Position | DUAL |
| Factory Lead Time | 12 Weeks |
| Packaging | Tube |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Number of Pins | 30 |
| Number of Terminations | 30 |
| Operating Supply Voltage | 25V |
| Operating Temperature | -40°C~85°C TA |
| Terminal Pitch | 0.5mm |
| Thickness | 1mm |
| HTS Code | 8542.39.00.01 |
| Output Voltage | 16V |
| Supply Voltage-Min (Vsup) | 6V |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| Height | 1.2mm |
| Lifecycle Status | ACTIVE (Last Updated: 3 days ago) |
| Width | 4.4mm |
| Supply Current-Max (Isup) | 5mA |
| Analog IC – Other Type | POWER SUPPLY SUPPORT CIRCUIT |
| Interface | I2C |
| Length | 7.8mm |
| Function | Battery Monitor |
| Battery Chemistry | Multi-Chemistry |
| Package / Case | 30-TFSOP (0.173, 4.40mm Width) |
| Fault Protection | Over Current, Over/Under Voltage, Short Circuit |
| Weight | 97.49401mg |
| Additional Feature | DETECTION THRESHOLD VOLTAGE= 0.7V |
| Number of Cells | 6 ~ 10 |
| Base Part Number | BQ7693003 |
